Audio input: 1 gab. CINCH, 8 – Audio atskaņošana, izmantojot koaksiālo kabeli
Image compression method: H.265+
Recorded image resolution: AHD / HD-TVI : 8M-N – 1920 x 2160 px, 5 Mpx – 2592 x 1944 px, HD-CVI : 8M-N – 1920 x 2160 px, 4 Mpx – 2560 x 1440 px, CVBS : 960H – 960 x 576 px, IP : max. 8.3 Mpx - 3840 x 2160 px
Supported hard drives: 1 x 8TB SATA
| Standard: | AHD, HD-CVI, HD-TVI, PAL, TCP/IP |
| Video inputs: | 8 pcs. BNC - AHD / HD-CVI / HD-TVI / CVBS |
| Video outputs: |
|
| Audio input: |
|
| Audio output: | 1 piece CINCH |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 |
| Recorded image resolution: |
8M-N – 1920 x 2160 px, 5 Mpx – 2592 x 1944 px, 5M-N – 1296 x 1944 px, 4 Mpx – 2560 x 1440 px, 4M-N – 1280 x 1440 px, 3 Mpx – 2048 x 1536 px, 1080p – 1920 x 1080 px, 720p – 1280 x 720 px, 8M-N – 1920 x 2160 px, 4 Mpx – 2560 x 1440 px, 4M-N – 1280 x 1440 px, 1080p – 1920 x 1080 px, 720p – 1280 x 720 px, 960H – 960 x 576 px, max. 8.3 Mpx – 3840 x 2160 px |
| Recording speed adjustment: | 8.3 Mpx IP @ 1 … 25 frame rate 8M-N @ 1 … 8 frame rate 5 Mpx @ 1 … 6 frame rate 5M-N @ 1 … 10 frame rate 4 Mpx @ 1 … 8 frame rate 4M-N @ 1 … 15 frame rate 3 Mpx @ 1 … 9 frame rate 1080p @ 1 … 15 frame rate 720p @ 1 … 25 frame rate 960H @ 1 … 25 frame rate for each of the channels |
| Working mode: |
/ IP + 8 x IP |
| Recording modes: | Manual, sensor, motion detection, schedule |
| Supported hard drives: | 1 x 8TB SATA |
| Backups on external media: | Copy of the recording (.avi) in USB (pendrive) format |
| Searching and playing recordings: | Search for a recording in the timeline or file list. Playback: forward, backward, fast, slow. Plays recordings from up to 4 cameras simultaneously |
| Network features: |
|
| Mobile phone access: | Port: 6000 or access via cloud
|
| Default IP address: | 192.168.1.88 |
| Default username/admin password: | admin / 12345 |
| Browser access ports: | 80, 5000, 554 |
| Access ports using PC application: | 80, 5000, 554 |
| Access ports using the mobile application: | 80, 5000, 6000 |
| Alarm inputs/outputs: | 4 / 2 |
| PTZ head rotation control: | Pelco-D, Pelco-P |
| Motion detection: | Screen division: 22 x 18 motion zones |
| USB: | 2 pcs. USB 2.0 |
| Mouse crew: | ✓ |
| IR remote control included: | ✗ |
| Source of energy supply: | 12 V DC / 2 A (power adapter included) |
| Colour: | Black |
| Weight: | 0.77 kg |
| Size: | 260 x 242 x 45 mm |
| Language selection: | Polish, English, Bulgarian, Czech, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Turkish, Hungarian, Italian |
| Country of origin: | China |
| Manufacturer / Brand: | APTI |
| WARRANTY: | 2 years |
