Audio input: 1 piece
Image compression method: AI Coding / Smart H.265+
Recorded image resolution: AHD / HD-CVI / HD-TVI : 5 Mpx – 2592 x 1440, 5M-N – 1296 x 1440, 4M-N – 1280 x 1440, IP : max. 6 Mpx – 3072 x 2048
Supported hard drives: 1 x 16 TB SATA
Selected features: Saderīga ar markas Dahua ierīcēm, kas darbojas (IoT) lietiskā interneta koncepcijā, Saderīga ar Coax Audio/Alarm, Inteliģenta attēla analīze
| Standard: | AHD, HD-CVI, HD-TVI, CVBS, IP |
| Video inputs: | 8 pcs. BNC |
| Video outputs: | 1 piece HDMI 1 piece VGA |
| Audio input: | 1 gab. – CINCH 8 – Audio atskaņošana, izmantojot koaksiālo kabeli, tikai HD-CVI |
| Audio output: | 1 piece CINCH |
| Image compression method: | AI Coding / Smart H.265+ / H.265 / Smart H.264+ / H.264 |
| Recorded image resolution: | AHD / HD-CVI / HD-TVI : 5 Mpx – 2592 x 1440 , 5M-N – 1296 x 1440 , 4M-N – 1280 x 1440, , 1080p – 1920 x 1080 , 1080N – 960x1080, , 720p – 1280x720, , CVBS : IP : |
| Recording speed adjustment: | 6 Mpx IP @ 1 … 25 frame rate 5 Mpx @ 1 … 6 frame rate 5M-N @ 1 … 20 frame rate 4M-N @ 1 … 25 frame rate 1080p @ 1 … 25 frame rate 1080N @ 1 … 25 frame rate 720p @ 1 … 25 frame rate 960H @ 1 … 25 frame rate |
| Working mode: | 8 times AHD / HD-CVI / HD-TVI / CVBS / IP + 4 x IP |
| Recording modes: | Manual, motion detection, schedule |
| Supported hard drives: | 1 x 16 TB SATA |
| Backups on external media: | Converting an image or recording frame from an archive to a USB drive |
| Searching and playing recordings: | Recording search: by time + timeline with recording type. Playback: forward, fast, slow, step by step Advanced search (up to a second) Inteliģentā mākslīgā intelekta sejas meklēšana – meklē sejas ierakstu arhīvā, izmantojot attēlus no datubāzes. |
| Network features: | Pilnīgs tīkla atbalsts, Ierakstu kopēšanas tālvadība, Iebūvēts tīmekļa serveris max. 128 on-line lietotāji |
| Mobile phone access: | Port: 37777 or access via cloud
Watch the video on how to perform P2P configurations on Dahua recorders and how to enable the mobile app |
| Alarm inputs/outputs: | ✗ |
| PTZ head rotation control: | IP Speed Dome cameras Control compatible with coax PTZ HD-CVI RS-485 - PELCO-D/P |
| Motion detection: | Screen division: 22 x 18 motion zones |
| Selected functions: |
|
| USB: | 1 piece USB 2.0 1 piece USB 3.0 |
| Mouse crew: | ✓ |
| IR remote control included: | ✗ |
| Source of energy supply: | 12 V DC / 2 A (power adapter included) |
| Colour: | Black |
| Weight: | 0.91 kg |
| Size: | 260 x 238 x 48 mm |
| Language selection: | poļu, angļu, čehu, dāņu, somu, franču, grieķu, spāņu, Holandiešu, vācu, portugāļu, krievu, rumāņu, serbu, slovāku, slovēņu, ungāru, itāļu |
| Country of origin: | China |
| Manufacturer / Brand: | DAHUA |
| WARRANTY: | 3 years |
