BCS POINT recorder BCS-P-NVR1604-A-4K(5)

BCS POINT BCS-P-NVR1604-A-4K(5) recorder

Key features:

16-channel IP recorder from BCS Point. Adapted to work with cameras up to 16 Mpx.

• 16-channel IP recorder
• NDAA compliance
• Support for 4 hard drives
• Support for 16 Mpx IP cameras
• Alarm 16/4, audio 1/1
• HDMI4K/VGA output

BCS Manager mobile app

BCS Manager is a free app version for operating IP CCTV systems on Android and iOS mobile phones. Allows you to view BCS brand NVR/XVR devices.

BCS Manager works both in the local Wi-Fi network and in the GSM network. It allows you to connect to devices that are available on the Internet using a fixed IP address or the BCS P2P cloud service (BCS P2P cloud requires appropriate device preparation).

Performance and scalability

Recorder BCS-P-NVR1604-A-4K(5) supports up to 16 IP channels and 4 hard drives with a total capacity of up to 16 TB, making it an ideal solution for medium and large surveillance systems. Thanks to advanced RAID support (1/5), it provides a high level of data security. Wide compatibility with third-party cameras (ONVIF) and support for many network protocols guarantee flexible integration into existing infrastructure.

Advanced AI features

The recorder is equipped with several artificial intelligence functions, such as face detection and matching, intelligent video analysis (SIP) function, vehicle detection and people counting. This allows you to quickly respond to potential threats and manage recordings more efficiently. AI works with both cameras and the recorder, offering full support for the latest generation systems.

Reliability and safety

Thanks to the ANR (Auto Network Replenishment) function, the recorder automatically synchronizes recordings from the cameras' microSD cards after a connection is lost and restored. In addition, the Pentaplex system provides simultaneous live viewing, recording, playback, archiving and remote access. The recorder complies with NDAA requirements, making it a suitable choice for government and corporate projects with increased security standards.

BCS POINT – NDAA Class Reliability and Security

BCS POINT series devices comply with NDAA requirements, which confirms their high manufacturing standards and compliance with international security standards. It is an ideal choice for applications in government agencies, critical infrastructure and anywhere where complete control over system security is important.

Imaging and archiving versatility

The recorder supports resolutions up to 16 Mpx and provides smooth image display in various configurations — from 1 to 16 channels simultaneously, including in corridor mode. Equipped with HDMI 4K and VGA outputs and various archiving options (USB flash drive, USB HDD), it allows you to conveniently manage video materials. Thanks to support for up to 128 users and remote access (computer, mobile app), the recorder is ideal for multi-station environments.

BCS MANAGER software

It was created to support devices from many product lines with a single application. Today it is an advanced program that can be used by both individual users and large monitoring centers. The application is characterized by simple and intuitive use, as well as the implementation of many functions that expand the operator's daily work.

BCS MANAGER - a program for operating BCS CCTV devices.

BCS Manager is a professional management system designed to provide comprehensive support for BCS video surveillance. It allows you to conveniently view live feeds, play back recordings, configure devices, and manage alarms and users from your computer. The program supports multiple locations simultaneously, offering features such as e-maps, recording schedules, and full integration with recorders and IP cameras. It is a reliable tool for professionals who need a central platform to effectively manage their CCTV system.

Technical specifications

Ai: 2×12MP@30, 2×4K@30, 6×4MP@30, 8×3MP@30, 12×1080P@30, 16×720P@30
