Resolution: 2304 x 1296, 1920 x 1080,
Sensors: 1/2.8 ”
Viewing angle: 82 °
LED white light range: 30 m
Image compression method: Smart H.265+ / Smart H.264+
Memory card slot: Micro SD card support up to 512GB
Audio: Two-way audio streaming support
Selected features: Wi-Fi 6 atbalsts – standarts, kas piedāvā lielāku ātrumu un labāku veiktspēju augstas satiksmes vidē,
Source of energy supply: 12 V DC
| Standard: | IP |
| Resolution: | 2304x1296 – 3 Mpx , 1920 x 1080 - 1080p , 1280x720 – 720p |
| Sensors: | 1/2.8” Progressive Scan CMOS |
| Lens: | 3.6 mm |
| Angle of visibility: | 82 ° |
| Optical zoom: | ✗ |
| Digital zoom: | ✗ |
| Infrared illumination reception area: | ✗ |
| LED white light range: | 30 m |
| Video output: | ✗ |
| Rotation speed (manual control): | Missing data |
| Preset rotation speed: | Missing data |
| Horizontal rotation range: | 0 ° … 345 ° – Rotation is limited by a switch |
| Vertical rotation range: | 0°…90° |
| RS-485 interface: | ✗ |
| Number of presets: | Missing data |
| Horizontal scan: | ✗ |
| Route settings: | ✓ |
| Image compression method: | Smart H.265+ / H.265 / Smart H.264+ / H.264B / H.264M / H.264H / MJPEG |
| Alarm inputs/outputs: | ✗ |
| Mainstream transmission speed: | 15 frame rate – 3 Mpx |
| Memory card slot: | Micro SD card support up to 512GB |
| Interface: |
|
| WEB Server: | Built-in, NVR compliant |
| Maximum number of online users: | Missing data |
| ONVIF: | ✓ |
| Audio: |
|
| Mobile phone access: | 37777 socket
|
| Default username/admin password: | admin / – Administrator password must be set during first launch |
| Default IP address: | 192.168.1.108 |
| Browser access ports: | 80, 37777 |
| Access ports using PC application: | 37777 |
| Access ports using the mobile application: | 37777 |
| RTSP URL: | rtsp://admin:password@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 – Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 – Sidestream |
| Intelligent image analysis: |
|
| Selected functions: |
|
| Source of energy supply: | 12 V DC / 1A |
| Power consumed: | ≤ 9W |
| Hull: | Speed Dome, Plastic |
| Colour: | White |
| Class of protection: | IP66 |
| Operating temperature: | -30°C … 55°C |
| Weight: | 0.6 kg |
| Size: | Ø 130 x 154 mm (bez kronšteina) |
| Language selection: | English |
| Manufacturer / Brand: | DAHUA |
| WARRANTY: | 3 years |
