Technical Specification:
| Support: | INTEGRA |
| Relay connection load, if the voltage is DC 24V: | max. 2 A |
| Selected features: | relay for controlling an electric trigger, latch or electromagnetic lock door position control input Alarms: ATTACK, FIRE, HELP calling from the keypad Microswitch detects keypad sabotage LED indicators show device status Blue key illumination |
| Source of energy supply: | 12V DC |
| Current consumption: | max. 66 mA |
| Operating temperature: | -10°C … 55°C |
| Weight: | 0.11 kg |
| Size: | 80 x 126 x 23 mm |
| Manufacturer / Brand: | SATEL |
| Warranty: | 2 years |
