Technical Specification:
| Compatible standards: | IEEE 802.11 b/g/n/e/i |
| Radio mikroshēmojums: | ESP8266 |
| Working mode: | Station / Soft AP / Station + Soft AP |
| Antenna type: | Internal |
| Interface: | UART 3.3 V, SDIO, SPI, I2C, I2S, GPIO, ADC, PWM |
| Frequency range: | 2.4 GHz |
| Receiver sensitivity: | 11b 11M : -91 dBm 11g 54M : -75 dBm 11n MCS7 : -72 dBm |
| Pieslēgšanās drošība: | WEP / TKIP / AES, WPA-PSK/WPA2-PSK |
| Operating temperature: | 0°C … 40°C |
| Weight: | 0.001 kg |
| Size: | 24 x 16 x 3.2 mm |
| Manufacturer / Brand: | Espressif |
| Warranty: | 2 years |
