| Entrances: |
8x 950 MHz … 2400 MHz 1x 47 MHz … 790 MHz – Aktīva – Iebūvēts filtrs LTE 1x 5 MHz … 862 MHz – Pasīva |
| Outputs: |
12x 5 MHz … 2400 MHz |
| Switching signals: |
14 V / 18 V 0 Hz / 22 kHz DiSEqC 2.0 |
| SAT gain (cable correction): |
6 … 14 dB |
| TV gain (cable correction): |
-1 … 5 dB |
| Insulation: |
Starp ieejām SAT/SAT > 30 dB Izejas > 30 dB SAT Izejas > 30 dB DVB-T |
| Maximum output level SAT: |
93 dBµV |
| Maximum output level for TV: |
85 dBµV |
| Preamplifier power supply: |
12V DC |
| Source of energy supply: |
230V AC |
| Weight: |
1.4 kg |
| Size: |
253 x 135 x 52 mm |
| Manufacturer / Brand: |
TERRA |
| Warranty: |
2 years |
