Technical Specification:
| Rated voltage: | 230V AC / 50Hz |
| Maximum voltage: | 250 V AC / 50 Hz |
| Rated current: | 10 A |
| Aizsardzības līmenis Up L/PE, N/PE: | ≤ 1.3 kV |
| Aizsardzības līmenis Up L/N: | ≤ 3 kV |
| Nominālā izlādes strāva (L/N, L/PE, N/PE): | 4 kA – 8/20 µs |
| Maksimālā izvades strāva (L/N, L/PE, N/PE): | 10 kA 8/20 µs (tips 2) |
| Operating mode alarm: | - |
| Connector type: | 2 x spaiļu plāksne |
| Housing: | Plastmasa montāža uz sliedes DIN, TS-35 |
| Weight: | 0.075 kg |
| Size: | 86 x 58 x 35 mm |
| Warranty: | 2 years |
