Technical Specification:
| Rated voltage: | 5V |
| Maximum voltage: | 6V |
| Surge system protection level (line-line): | ≤ 40 V |
| Voltage protection line-ground: | ≤ 600 V |
| Nominālā izlādes strāva (līnija-līnija): | 100 A (8/20µs) |
| Rated discharge current (line-ground): | 100 A (8/20µs) |
| Maksimālā izlādes strāva (līnija-līnija): | 135 A (8/20µs) |
| Maximum discharge current (line-ground): | 135 A (8/20µs) |
| Load: | < 20 pF |
| Shielded cable pairs: | 1-2, 3-6, 4-5, 7-8 |
| Kontaktligzdu veidi: | RJ45 (8P8C) |
| Size: | 66 x 60 x 30 mm |
| Weight: | 0.05 kg |
| Warranty: | 2 years |
