Technical Specification:
| Frequency range: | 47 MHz … 862 MHz |
| Reinforcement: | 18 dB … 20 dB 27 dB … 30 dB iestatīšana ar slēdzi |
| Number of inputs/outputs: | 1 / 1 + 1 (1 x test: -30dB) |
| Gain adjustment: | 17 dB |
| Regulējams slīpums: | 17 dB |
| Maximum output level IMD3=60 dB DIN45004B: | 97 dBµV |
| Noise factor: | ≤ 8.5 dB |
| Source of energy supply: | 230V AC |
| Power consumption: | ≤ 3.5W |
| Operating temperature: | -20°C … 50°C |
| Weight: | 0.33 kg |
| Size: | 133 x 63 x 39 mm |
| Manufacturer / Brand: | TERRA |
| Warranty: | 2 years |
