It can be used to increase the maximum load of the controller transistor output line, as well as for galvanic isolation of the output line and the load point; Number of relay outputs: 1
Source of energy supply: 12 V … 230 V AC / DC
Relay load: 16 A / 250 V AC
Exit: 1 x NO/NC
Manufacturer / Brand: ORNO
| Number of relay outputs: | 1 |
| Source of energy supply: | 12 V … 230 V AC / DC |
| Nominālais elektroenerģijas patēriņš: | ≤ 1.5 W |
| Relay load: | 16 A / 250 V AC (max) 16 A / 24 V DC (max) |
| Exit: | 1 x NO/NC |
| Selected characteristics: |
|
| Operating temperature: | -20°C … 50°C |
| Weight: | 0.065 kg |
| Size: | 97 x 17 x 65 mm |
| Manufacturer / Brand: | ORNO |
| WARRANTY: | 2 years |
