Technical Specification:
| Detection angle: | 90° |
| Application: | Internal |
| Sensor type: | Passive infrared (PIR) |
| Reception area: | 12 m |
| Sensitivity setting: | 3-stage |
| Alarm output: | 24 V / 50 mA NC |
| Alarm time: | > 2 s |
| Digital temperature compensation: | - |
| Resistant to animals: | - |
| Source of energy supply: | 9 V … 15 V DC / 10.6 mA |
| Target movement speed: | 0.3 … 3 m/s |
| Operating temperature: | -10°C … 55°C |
| Size: | 95 x 63 x 41 mm |
| Manufacturer / Brand: | TEXECOM |
| Warranty: | 2 years |
