Technical Specification:
| Type: | Quad 6 ° |
| Input frequency: | 10.7 GHz … 11.7 GHz 11.7 GHz … 12.75 GHz |
| Output frequency: | 950 – 1950 MHz 1100 – 2150 MHz |
| Oscillation generator frequency: | 9.75GHz / 10.6GHz |
| Noise factor: | 0.2 dB |
| Number of outputs: | 4 gab. Ligzda F |
| Output impedance: | 75 Ω |
| LNB switch: | DiSEqC |
| Reinforcement: | 55 dB |
| Polarization switching H/V: | 13 / 18V |
| Lane switching: | 22 kHz |
| Recommended satellite dish diameter: | 80cm |
| Fastener diameter: | 23 mm / 40 mm |
| Operating temperature: | -30 °C … +60 °C |
| Weight: | 0.516 kg |
| Size: | 100 x 135 x 120 mm |
| Manufacturer / Brand: | INVERTO |
| Warranty: | 2 years |
