Technical Specification:
| Number of rays: | 1 |
| Detection type: | beam 1 damage |
| Outdoor reception area: | 3 … 15 m |
| Reception area inside the premises: | 3 … 20 m |
| Stream characteristics: | 940 nm – Modulated infrared beam |
| Alarm time: | ≥ 0.1s |
| Anti-sabotage connection: | - |
| Corner adjustment range: | - |
| Assembly: | on a wall or pole |
| Source of energy supply: | 9 V … 16 V DC / AC – setting with switch |
| Current consumption: | 20 mA – Transmitter, 18 mA – Receiver |
| Alarm output: | Relay (AC/DC 36V max. 1A) |
| Protection class: | IP66 |
| Operating temperature/relative humidity: | -25 °C … 55 °C / max. 95 % |
| Transmitter or receiver dimensions: | 49 x 76 x 22 mm |
| Angle adjustment range: | 0.036 kg |
| Warranty: | 2 years |
