Audio input: 1 gab. CINCH, 8 – Audio atskaņošana, izmantojot koaksiālo kabeli </span>;>Image compression method: H.265 </span>;>Recorded image resolution: AHD / HD-TVI : 5M-N, 4M-N, 1080N, IP : max. 4 Mpx </span>;>Supported hard drives: 1 x 6TB SATA </span>;
<table>
Standard:
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
Video inputs:
8 pcs. BNC
Video outputs:
1 piece HDMI
1 piece VGA
Audio input:
Audio output:
1 piece CINCH
Image compression method:
H.265 / H.264
Recorded image resolution:
5M-N – 1296 x 1944 – kamerām 12 frame rate ,
4M-N – 1280 x 1440 – kamerām 15 frame rate ,
1080N – 960x1080, ,
720p – 1280 x 720
960H – 960 x 576 ,
max. 4 Mpx – 2560 x 1440
Recording speed adjustment:
4 Mpx IP @ 1 … 25 frame rate ,
5M-N @ 1 … 6 frame rate ,
4M-N @ 1 … 8 frame rate ,
1080N @ 1 … 15 frame rate ,
720p @ 1 … 15 frame rate ,
960H @ 1 … 15 frame rate
for each of the channels
Working mode:
4 times AHD / HD-CVI / HD-TVI / CVBS + 4 x AHD / HD-CVI / HD-TVI / CVBS / IP + 4 x IP
Recording modes:
Manual, motion detection, schedule
Supported hard drives:
1 x 6TB SATA
Backups on external media:
Converting an image or recording frame from an archive to a USB drive
Searching and playing recordings:
Recording search: by time + timeline with recording type. Playback: forward, fast, slow, step by step
Advanced search (up to a second)
1/4/8 kanālu sinhronā atskaņošana
Network interface:
1 x RJ-45 – 10/100 Base-TX
Network features:
Full network support, Remote recording copy, Built-in web server
max. 128 online users
Mobile phone access:
Port: 80 or access via cloud
USB:
2 times USB 2.0
Alarm inputs/outputs:
PTZ head rotation control:
IP Speed Dome cameras
Motion detection:
Mouse crew:
IR remote control included:
Source of energy supply:
12 V DC / 2 A (power adapter included)
Power consumed:
≤ 8 W (bez HDD)
Colour:
Black
Weight:
0.86 kg
Size:
255 x 260 x 46 mm
Language selection:
English, Czech, French, Spanish, Dutch, German, Polish, Portuguese, Slovak, Italian
Manufacturer / Brand:
BCS BASIC
WARRANTY:
3 years
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP Tīkla Video Ierakstītājs Videoreģistrators BCS-B-XVR0801(2.0) 8 KANĀLI BCS BASIC
Estimated Delivery Dates
91,25 €
Availability: 0
Additional information
| Svars | 1,2260 kg |
|---|---|
| Dimensions | 405 × 270 × 75 cm |
