| Standard: |
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP |
| Video inputs: |
4 pcs. BNC |
| Video outputs: |
1 pc HDMI 4K 1 pc VGA |
| Audio input: |
1 pc. CINCH , 4 pcs. Coaxial audio – Audio playback via coaxial cable |
| Audio output: |
1 pc. CINCH |
| Image compression method: |
AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Recorded image resolution: |
AHD / HD-CVI / HD-TVI : 8.3 Mpx 4K UHD – 3840 x 2160 , 5 Mpx – 2592 x 1944 , 3.7 Mpx – 2560 x 1440 , 4M-N – 1280 x 1440 , 1080p – 1920 x 1080 , 720p – 1280 x 720 ; HD-CVI : 6 Mpx – 3072 x 2048 ; AHD / HD-TVI : 3 Mpx – 2048 x 1536 , CVBS : 960H – 960 x 576 , IP : max. 8.3 Mpx 4K UHD – 3840 x 2160 |
| Recording speed adjustment: |
8.3 Mpx IP @ 1 … 25 kadru nomaiņas ātrums 8.3 Mpx @ 1 … 7 kadru nomaiņas ātrums 6 Mpx @ 1 … 10 kadru nomaiņas ātrums 5 Mpx @ 1 … 12 kadru nomaiņas ātrums 3.7 Mpx @ 1 … 15 kadru nomaiņas ātrums 4M-N @ 1 … 25 kadru nomaiņas ātrums 3 Mpx @ 1 … 15 kadru nomaiņas ātrums 1080p @ 1 … 25 kadru nomaiņas ātrums 720p @ 1 … 25 kadru nomaiņas ātrums 960H @ 1 … 25 kadru nomaiņas ātrums katram no kanāliem |
| Working mode: |
4 x HD-TVI / AHD / HD-CVI / CVBS / IP + 4 x IP |
| Recording modes: |
Manual, motion detection, schedule |
| Supported hard drives: |
1 x 10TB SATA |
| Backups on external media: |
Backup to USB (pendrive, external drive) |
| Searching and playing recordings: |
Search for recordings in the timeline or file list: play forward, fast forward, slow down. Synchronous playback in 1/4 channels |
| Network interface: |
1 x RJ-45 – 10/100 Base-TX |
| Network functions: |
Full network support, Remote control of recording copying, Built-in web server max. 128 on-line users |
| Network protocols: |
HTTP, HTTPS, TCP/IP , IPv4/IPv6 , UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search, ONVIF |
| Default IP address: |
DHCP or 192.168.1.64 |
| Default username/admin password: |
admin / – Administrator password must be set during first launch |
| Mobile phone access: |
Port: 8000 or cloud access Android: Free BCS Manager app iOS (iPhone): Free BCS Manager app |
| Browser access ports: |
80 |
| Access ports using PC application: |
554 RTSP, 8000 – CMS application |
| Access ports using the mobile application: |
8000 |
| ONVIF port: |
80 |
| RTSP URL: |
rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no01/ – Main stream rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no02/ – Side stream |
| USB: |
2 x USB 2.0 |
| Alarm inputs/outputs: |
- |
| PTZ head rotation control: |
IP Speed Dome cameras |
| Motion detection: |
Screen division: 22 x 18 motion zones |
| Selected features: |
Inteliģenta attēla analīze : ielaušanās , līnijas šķēršošana , veido detekcija SMD PLUS – objekta meklēšana, kas tiek klasificēts kā: cilvēks, mehāniskais transportlīdzeklis POS – saderīgs ar tirdzniecības vietās instalētām ierīcēm un datu attēlošanu pārklāta teksta veidā noteiktā kanāla |
| Mouse crew: |
- |
| IR remote control included: |
- |
| Source of energy supply: |
12 V DC / 2 A (power adapter included) |
| Power consumption: |
max. 7 W |
| Colour: |
Black |
| Weight: |
0.48 kg |
| Size: |
211 x 205 x 45 mm |
| Language selection: |
Polish, English, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Hungarian, Italian |
| Manufacturer / Brand: |
BCS Line |
| Warranty: |
3 years |
