| Device name |
BCS-L-EIP15FSR3-Ai1 |
| Product line |
BCS LINE |
| Type Camera |
Dome-shaped |
| Resolution |
5 Mpx
| Sensors |
1/2.7 inch CMOS |
| Scanning system |
Progressive scan |
| Pixels |
2592(H)×1944(V) |
| RAM |
512MB |
| ROM |
128MB |
| Lens |
Fixed |
| Focal length |
2.8mm
| Aperture |
F1.6 |
| Focus |
Fixed |
| Shutter |
Fixed |
| Digital zoom |
16× |
| Viewing angle |
A: 97° Vertikāls: 71° Dziļums: 129° |
| DORI |
Noteikt 64 m/ Novērot 25 m/ Atpazīt 13 m/ Identificēt 6 m |
| Camera sensitivity |
0,005 luksi (krāsu, F1.6, 30IRE) 0,0005 luksi (melnbalts, F1.6,30IRE) 0 luksi (IR) |
| Signal to noise ratio |
56 dB |
| White balance |
(AWB) Automatic / Manual |
| WDR |
120dB |
| Backlight compensation |
BLC/HLC/WDR (120dB) |
| Shutter speed |
Auto/Manual 1/3~1/100000 s |
| Pastiprinājuma vadība |
(AGC) Automatic/Manual |
| Noise reduction |
3D DNA |
| Apvēršana Attēls |
Mirror image, rotation 0°/90°/180°/270° |
| Number of streams |
2 |
| Resolutions |
5M(2592×1944) / 4M(2688×1520) / 3M(2304×1296) / 2M(1920×1080) / 1,3M(1280×960) / 720P(1280×720) / D1(704×576/704×480) / VGA(640×480) / CIF(352×288/352×240) |
| Straumēšana Galvenā |
2592×1944(1~20 kadri/s) 2688×1520(1~25/30 kadri/s) |
| Secondary stream |
704×576(1~25 kadri/s) 704×480(1~30 kadri/s) |
| Bit rate |
H.264: 3 Kbps~8192 Kbps H.265: 3 Kbps~8192 Kbps |
| Video compression |
H.265 / H.265+ / H.264 / H.264+ / MJPEG
| Day/Night |
ICR mechanical filter Infrared |
| Illuminator type |
IR LEDs |
| Illuminator |
30 m |
| Microphone |
Yes |
| Audio compression |
G.711A / G.711Mu / G.726 / PCM |
| Memory card slot |
microSD 256 GB |
| Support |
web service, CMS BCS Manager (Windows/Linux/MAC), mobile app (iOS, Android) |
| Motion detection |
4 |
| Mask privacy |
4 |
| Network |
RJ-45 10/100Mbps |
| Compatibility |
ONVIF(S/G/T) |
| Protocols |
IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP |
| Power source type |
12V DC / PoE(802.3af) |
| Power consumption |
maks. 6.7 W |
| Body color |
White |
| IP protection class |
IP67 |
| Operating conditions |
-40°C~+60°C max. 95% relative humidity |
| Dimensions |
Ø106×94 mm |
| Weight |
0.39 kg |
| Ai - built-in intelligence |
Built-in intelligent image recognition and analysis algorithms |
| AI - Perimeter Protection |
Entry into the territory, crossing the line |
| Ai — atpazīšana Objekti |
Personas/transportlīdzekļa atpazīšana, ja tiek ielauta kāda zona vai šķērsota līnija, samazina viltus trauksmes signālu aktivizēšanu. |
| Mākslīgais intelekts – SMD |
SMD Plus |
