BCS LINE kamera BCS-L-DIP58VSR4-Ai1(2)
Modelis: BCS-L-DIP58VSR4-Ai1(2)
Key features:
- 8Mpx kupola IP Kamera
- 1/1,8 collu PS CMOS sensors
- SkyLight technology
- 2,7–12 mm motorizēta lēca
- WDR 120 dB
- IR 40 m
- Alarm 1/1, Audio 1/1, Microphone
- IP67, IK10 housing
- Built-in smart features
Technical specifications
| Device name | BCS-L-DIP58VSR4-Ai1(2) |
| Product line | BCS LINE |
| Camera type | Dome-shaped |
| Resolution | |
| Sensors | 1/1.8 inch CMOS |
| Scanning system | Progressive scan |
| Pixels | 3840(H)×2160(V) |
| RAM | 1GB |
| ROM | 128MB |
| Lens | mototālummaiņa |
| Focal length | 2,7–12 mm |
| Opening | F1,5 |
| Focus | Automatic / manual |
| Aizvara diafragma | Automatic |
| Optical zoom | 4× |
| Digital zoom | 16× |
| Viewing angle | A: 113°~47° Vertikāla: 60°~26° Dziļums: 133°~53° |
| DORI | Noteikšana 83~190 m / Novērošana 33~76 m / Atpazīšana 17~38 m / Identificēšana 8~19 m |
| Camera sensitivity | 0,003 luksi (krāsu, F1,6, 30IRE) 0,0005 luksi (F1,6, melnbalts,30IRE) 0 luksi (IR) |
| Signal to noise ratio | 56 dB |
| White balance | (AWB) Automatic / Manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR (120 dB) / SSA |
| Shutter speed | Auto/Manual 1/3~1/100000 s |
| Gain control | (AGC) Automatic/Manual |
| Noise reduction | 3D DNA |
| Attēls Stabilizācija | Elektroniskā (EIS) |
| Fog prevention | Electronic |
| Image rotation | Mirror, rotation 0°/90°/180°/270° |
| Number of streams | 3 |
| Resolution | 8M(3840×2160) / 6M(3072×2048) / 5M(3072×1728)(2592×1944) / 4M(2688×1520)(2560×1440) / 3M(2048×1536)(2304×1296) / 2M(1920×1080) / 1,3 M (1280 × 960) / 720P (1280 × 720) / D1 (704 × 576/704 × 480) / VGA (640 × 480) / CIF (352 × 288/352 × 240) |
| Main stream | 3840 × 2160 (1–25/30 kadri/s) |
| Second stream | 704 × 576 (1-25 fps) 704 × 480 (1-30 fps) |
| Third stream | 1920 × 1080 (1-25/30 fps) |
| Bit rate | |
| Video compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG / Ai encoding |
| Day/Night | ICR mechanical IR filter |
| Illuminator type | IR LEDs |
| Illuminator | 40 m |
| Microphone | Yes |
| 1 | |
| Audio output | 1 |
| Audio compression | G.711A / G.711Mu / G.723 / G.726 / PCM |
| Alarm input | 1 |
| Alarm output | 1 |
| Memory card slot | microSD 256 GB |
| Support | Tīmekļa pakalpojums, CMS BCS pārvaldnieks (Windows/Linux/MAC), mobilā lietotne (iOS,android) |
| Motion detection | 4 |
| Privacy masks | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P |
| Tips Barošanas avots | 12V DC / PoE (802.3af) |
| Energy consumption | maks. 8,5 W |
| Body color | White |
| IP protection class | IP67 |
| IK10 | Yes |
| Operating conditions | -30 °C~+60 °C max. 95 % relative humidity |
| Dimensions | Ø122 × 94 mm |
| Weight | 0,71 kg |
| Mākslīgais intelekts — iebūvētas intelektiskās funkcijas | Iebūvēta intelektiskā attēlu atpazīšana un analīze algoritmi |
| Artificial Intelligence - Perimeter Protection | Ieeja zonā, šķērsojot līniju |
| Artificial Intelligence - Object Recognition | Personas/transportlīdzekļa atpazīšana, ja ielaušanās zonā, šķērsojot līniju, samazina viltus trauksmes signālu aktivizēšanu. |
| Artificial Intelligence — SMD |
