BCS LINE kamera BCS-L-EIP18FSR3-Ai1
Modelis: BCS-L-EIP18FSR3-Ai1
Key features:
- 8Mpx kupola IP Kamera
- 1/2,7 collu PS CMOS sensors
- SkyLight technology
- 2.8mm fixed lens
- WDR120dB
- IR 30 m
- Microphone
- IP67 housing
- Built-in smart features
Technical specifications
| Device name | BCS-L-EIP18FSR3-Ai1 |
| Product line | BCS LINE |
| Type Camera | Dome-shaped |
| Resolution | 8 Mpx |
| Sensors | |
| Scanning system | Progressive scan |
| Pixels | 3840(H)×2160(V) |
| RAM | 256MB |
| ROM | 128MB |
| Lens | Fixed |
| Focal length | 2.8mm |
| Aperture | F2.0 |
| Focus | Fixed |
| Shutter | Fixed |
| Digital zoom | 16× |
| Viewing angle | A: 106° Vertikāls: 56° Dziļums: 125° |
| DORI | Noteikšana 88 m / Novērošana 35 m / Atpazīšana 17 m / Identifikācija 9 m |
| Camera sensitivity | 0,009 luksi (krāsu, F1.6, 30IRE) 0,0009 luksi (melnbalts, F1,6,30IRE) 0 luksi (IR) |
| Signal to noise ratio | 56 dB |
| White balance | (AWB) Automatic / Manual |
| WDR | 120dB |
| Backlight compensation | BLC/HLC/WDR (120dB) |
| Shutter speed | Auto/Manual 1/3~1/100000 s |
| Pastiprinājuma vadība | (AGC) Automatic/Manual |
| Noise reduction | 3D DNA |
| Apvēršana Attēls | Mirror, rotation 0°/90°/180°/270° |
| Number of streams | 2 |
| Resolutions | 8M(3840×2160) / 6M(3072×2048) / 5M(3072×1728)(2592×1944) / 4M(2688×1520) / 3M(2048×1536)(2304×1296) / 2M(1920×1080) / 1,3M(1280×960) / 720P(1280×720) / D1(704×576/704× 480) / VGA (640 × 480) / CIF (352 × 288/352 × 240) |
| Main stream | 3840 × 2160 (1–20 kadri/s) |
| Second stream | 704 × 576 (1-25 fps) 704 × 480 (1-30 fps) |
| Bit rate | |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/Night | ICR mechanical IR filter |
| Illuminator type | IR LEDs |
| Illuminator | 30 m |
| Microphone | Yes |
| Audio compression | G.711A / G.711Mu / G.726 / PCM |
| Memory card slot | microSD 256 GB |
| Support | web service, CMS BCS Manager (Windows/Linux/MAC), mobile app (iOS, Android) |
| Kustība noteikšana | 4 |
| Privacy masks | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Boujour |
| Tips Barošanas avots | 12VDC / PoE(802.3af) |
| Barošana patēriņš | maks. 5.4W |
| Body color | White |
| IP protection class | IP67 |
| Operating conditions | -40°C~+60°C max. 95% relative humidity |
| Dimensions | Ø106×94mm |
| Weight | 0.39 kg |
| Ai - built-in intelligence | Built-in intelligent image recognition and analysis algorithms |
| AI - Perimeter Protection | Entering the zone, crossing the line |
| Ai — atpazīšana Objekti | Personas/transportlīdzekļa atpazīšana, ja tiek ielauta kāda zona vai šķērsota līnija, samazina viltus trauksmes signālu aktivizēšanu. |
| Mākslīgais intelekts – SMD | SMD Plus |
