| Device name |
BCS-L-EIP25FSR5-Ai1 |
| Product line |
BCS LINE |
| Camera type |
Dome-shaped |
| Resolution |
5 Mpx |
| Sensors |
1/2.7” CMOS
| Skenēšana Sistēma |
Progressive scan |
| Pixels |
2960(H)×1688(V) |
| RAM |
512MB |
| ROM |
128MB |
| Lens |
Fixed |
| Focal length |
2.8mm |
| Aperture |
F1.4 |
| Focus |
Fixed |
| Shutter |
Fixed |
| Digital Zoom |
16× |
| Viewing angle |
A: 97° Vertikāls: 71° Dziļums: 129° |
| DORI |
Atklāšana 64 m/ Novērošana 25 m/ Atpazīšana 13 m/ Identificēšana 6 m |
| Camera sensitivity |
0,005 luksi (krāsu, F1,4, 30IRE) 0,0005 luksi (melnbalts, F1,4,30IRE) 0 luksi (IR) |
| Signal-to-noise ratio |
56 dB |
| White balance |
(AWB) Automatic / Manual |
| WDR |
120dB |
| Backlight compensation |
BLC/HLC/WDR (120dB) |
| Shutter speed |
Auto/Manual 1/3~1/100000 s |
| Pastiprinājuma vadība |
(AGC) Automātiski / manuāli |
| Noise reduction |
3D DNA |
| Fog prevention |
Electronic |
| Image rotation |
Mirror, rotation 0°/90°/180°/270° |
| Number of streams |
3 |
| Resolutions |
5M(2960×1668) / 4M(2880×1620)(2688×1520)(2560×1440) / 3M(2304×1296)(2048×1536) / 2M(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF (352×288/352×240) |
| Mainstream |
2880×1620 (1–20 kadri/s) 2960×1668 (1–20 kadri/s) 2688×1520 (1–25/30 kadri/s) |
| Second stream |
704×576 (1–25 kadri/s) 704×480 (1–30 kadri/s) |
| Third stream |
1920×1080 (1-25/30 fps) |
| Bit rate |
H.264: 3 Kbps~8192 Kbps H.265: 3 Kbps~8192 Kbps
| Video compression |
H.265+ / H.265 / H.264+ / H.264 / MJPEG / AI kodēšana |
| Day/Night |
ICR mechanical IR filter |
| Illuminator type |
IR LEDs |
| Illuminator |
50 m |
| Microphone |
Yes |
| Audio compression |
G.711A / G.711Mu / G.723 / G.726 / PCM |
| Memory card slot |
microSD 256 GB |
| Support |
web service, CMS BCS Manager (Windows/Linux/MAC), mobile app (iOS, Android) |
| Motion detection |
4 |
| Masku privātums |
4 |
| Network |
RJ-45 10/100Mbps |
| Compatibility |
ONVIF (S/G/T) |
| Protocols |
IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE,SNMP |
| Power source type |
12 V V / PoE(802.3af) |
| Energy consumption |
maks. 8,9 W |
| Body color |
White |
| IP protection class |
IP67 |
| Operating conditions |
-40 °C–+60 °C maks. 95 % relatīvais mitrums |
| Dimensions |
Ø106 × 93,6 mm |
| Weight |
0.5 kg |
| Mākslīgais intelekts — iebūvētas intelektiskās funkcijas |
Iebūvēta intelektiskā attēlu atpazīšana un analīzes algoritmi |
| Artificial Intelligence - Perimeter Protection |
Ieeja zonā, šķērsojot līniju |
| Artificial Intelligence - Object Recognition |
Personas/transportlīdzekļa atpazīšana, ja ielaušanās zonā, šķērsojot līniju, samazina viltus trauksmes signālu aktivizēšanu. |
| Artificial Intelligence — SMD |
SMD 4.0
