Technical Specification:
| Standard: | HD-CVI , HD-TVI , AHD , PAL |
| Sensors: | 1/2.7” Progressive Scan CMOS |
| Matrix size: | 2.1 Mpx |
| Resolution: | 1920 x 1080 – 1080p , 1280 x 720 – 720p , 960 x 576 – 960H , PAL |
| Infrared illumination detection area: | 20 m |
| IR illuminator power adjustment: | Automatic |
| Lens: | 2.8 mm |
| Viewing angle: | 103 ° (manufacturer's data) 100 ° (our tests) |
| Signal to noise ratio (S/N): | > 65 dB |
| Video output: | HD-CVI / HD-TVI / AHD / PAL , 1 Vpp / 75 Ω |
| Audio: | - |
| Selected features: | D-WDR – Plašs apgaismojuma dinamikas diapazons 2D-DNR – Digitāla trokšņa redukcija BLC/HLC – fona / spēcīgas gaismas kompensācija AGC – Automātiska attēla pastiprinājuma regulēšana ICR – infrasarkano staru mehāniskais filtrs Mirror – spoguļattēls Automātisks baltā balanss Sharpness – Attēla kontūru asums |
| OSD screen menu: | OSD menu available using DAHUA video recorders |
| Source of energy supply: | 12 V DC / 220 mA |
| Power consumption: | ≤ 2.7 W |
| Housing: | Dome, Alumīnijs |
| Colour: | White |
| Anti-vandalism: | - |
| Protection class: | IP67 |
| Operating temperature: | -40°C … 60°C |
| Weight: | 0.27 kg |
| Size: | Ø 94 x 78 mm |
| Language selection: | Polish, English, French, Spanish, German, Portuguese, Russian, Italian |
| Manufacturer / Brand: | DAHUA |
| Warranty: | 3 years |
