HARTTE S12UP electric strike series S 12V AC/DC with internal memory
” class=”row”>
HARTTE S12UP electric strike S series 12V AC/DC with internal memory – description
S series electric strikes are the most versatile electric strikes in all respects. They have a symmetrical body, an adjustable hook in the range of 4 mm and a wide range of models with various options and additional functions. They are used in wooden, steel, aluminum and PVC doors in private and public buildings, used in access control systems in offices, commercial and industrial facilities, as well as in apartment buildings.
electrical memory specification
- Universal for use on left and right doors
- NC (normally closed) operating mode
- Symmetrical design
- Dimensions (W x H x D): 20.5 x 75 x 28.5 (mm)
- Opening cycle 350kg u20.li 0 000
- 4 mm adjustable impact force
- Voltage tolerance (V): 10-14
- Resistance (Ohms): 21
- AC current consumption (mA): 400
- DC current consumption (mA): 570
- Continuous operation without power: with internal memory
