Resolution: 3288 × 1850 3200 × 1800 2880 × 1620 2688 × 1520 2048 × 1536 2304 × 1296 1920 x 1080, 1280 x 960, 1280 x 720 Sensors: 1/1.8 " Viewing angle: 92 ° LED white light range: 50 m Memory card slot: Micro SD card support up to 256GB Audio: Built-in microphone, Source of energy supply: PoE (802.3af), 12V DC
Standard: |
IP |
| Resolution: |
3288 × 1850 – 6 Mpx , 3200 × 1800 – 6 Mpx , 2880 × 1620 – 5 Mpx , 2688 × 1520 – 4 Mpx , 2048 × 1536 – 3 Mpx 2304 × 1296 – 3 Mpx , 1920 x 1080 - 1080p , 1280x960 – 1.3 Mpx , 1280x720 – 720p |
Sensors: |
1/1.8" Progressive Scan CMOS |
| Lens: |
2.8 mm |
Angle of visibility: |
92 ° |
| LED white light range: |
50 m |
Lighting: |
0.0007 Lux / F1.0 (color) |
| Signal-to-sound ratio (S/N): |
> 56 dB |
Memory card slot: |
Micro SD card support up to 256GB |
| Image compression method: |
Smart H.265+ / Smart H.264+ / H.265 / H.264 / H.264H / H.264B |
Alarm inputs/outputs: |
 |
| Audio: |
Built-in microphone, Audio signal transmission over the network, Sound detection |
Mainstream transmission speed: |
20 frame rate @ 6 Mpx |
| Network interface: |
10/100 Base-T (RJ-45) |
WEB Server: |
Built-in |
| Maximum number of online users: |
20 |
ONVIF: |
 |
| Mobile phone access: |
Port: 37777 or access via cloud Android: Free application DMSS iOS (iPhone): Free app DMSS |
Default IP address: |
192.168.1.108 |
| Default username/admin password: |
admin / – Administrator password must be set during first launch |
Browser access ports: |
80, 37777 |
| Access ports using PC application: |
37777 |
Access ports using the mobile application: |
37777 |
| ONVIF socket: |
80 |
RTSP URL: |
rtsp://admin:password@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 – Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 – Sidestream |
| Intelligent image analysis: |
burglary – classification of persons and vehicles crossing the line – classification of persons and vehicles video sabotage change of scene SMD PLUS – search for an object classified as: person, motor vehicle |
Selected functions: |
AI-ISP – technology that allows the camera to easily adapt to the scene, creating high-quality images that reveal fine details of objects. WDR – 120 dB – Wide dynamic range of lighting 3D-DNR - Digital Noise Reduction ROI – improving the quality of selected image fragments Compatible with NAS – Network Attached Storage – helps add storage resources to a computer network BLC/HLC – Backlight/High Light Compensation Day/night mode Automatic white balance AGC - Automatic gain control Motion detection – max. 4 zones Privacy zones – max. 4 Image rotation and mirroring Built-in white light illuminator (LED): 4 diodes |
| Source of energy supply: |
PoE (802.3af), 12 V DC / 510 mA |
Power consumed: |
≤ 7.4 W @ PoE ≤ 6.1W @ 12V |
| Hull: |
Bullet – Metāla |
Colour: |
White |
| Class of protection: |
IP67 |
Mechanical protection class: |
 |
| Operating temperature: |
-40°C … 60°C |
Weight: |
0.57 kg |
| Size: |
198 x 80 x 76 mm |
Language selection: |
Polish, English, Czech, French, Spanish, Dutch, German, Russian, Portuguese, Romanian, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: |
DAHUA |
WARRANTY: |
3 years |
