Technical Specification:
| Entrances: | 8x 950 MHz … 2400 MHz 1x 47 MHz … 790 MHz Aktīva – Iebūvēts filtrs LTE 1x 5 MHz … 862 MHz Pasīva |
| Outputs: | 24x 5 MHz … 2400 MHz |
| Switching signals: | 14 V / 18 V 0 Hz / 22 kHz DiSEqC 1.0 DiSEqC 2.0 |
| SAT gain (cable correction): | 5 … 12 dB |
| TV gain (cable correction): | -1 … 4 dB |
| Insulation: | Starp ieejām SAT/SAT > 30 dB Izejas > 30 dB SAT Izejas > 30 dB DVB-T |
| Maximum output level SAT: | 93 dBµV |
| Maximum output level for TV: | 81 … 85 dBµV |
| Preamplifier power supply: | 12V DC |
| Source of energy supply: | 230V AC |
| Weight: | 1.6 kg |
| Size: | 293 x 135 x 52 mm |
| Manufacturer / Brand: | TERRA |
| Warranty: | 2 years |
