| Number of supported transitions: |
11 |
| Entrances: |
66 |
| Outputs: |
44 |
| Number of users: |
max. 12000 - Number of identifiers |
| Number of media per identifier: |
8 - Contactless card, PIN, fingerprints, etc. |
| Number of permits per identifier: |
100 |
| Buffer memory: |
Event buffer 8 000 000 |
| Compatible with MCT readers: |
16 pcs. |
| Adding readers: |
4 pcs - Wiegand / PRT |
| Number of connection points: |
22 |
| Number of access terminals: |
44 |
| Number of access zones: |
22 |
| Number of alarm zones: |
22 |
| Number of automation nodes: |
22 |
| Battery support: |
12 V / 7 Ah |
| Communication: |
Ethernet - RJ-45 socket RS-485 interface RACS 5 v2 (Roger) |
| Selected characteristics: |
VISO ST software integrated support Functions in the VISO ST system: - MSSQL database - work in distributed systems - multi-station work - monitoring of transitions with video preview - T&A event reporting - maximum number of transitions in the system : 128 |
| Source of energy supply: |
17 ... 22 V AC 10 ... 15 V DC 22 ... 26 V DC |
| Operating temperature: |
5 °C ... 40 °C |
| Allowable relative humidity: |
10 % ... 95 % (non-condensing) |
| Weight: |
0.14 kg |
| Size: |
175 x 72 x 30 mm |
| Manufacturer / Brand: |
ROGER |
| Warranty: |
3 years |
