Videodomofons tiek uzstādīts virsapmetuma korpusā; Viewing angle: 70 ° </span>;>IR emitter</span>;>Selected characteristics: Iespēja pieslēgt izejas pogu un herkonu, lai kontrolētu durvju statusu </span>;>Source of energy supply: From the inner panel </span>;>Screen: 7 " ietilpīgs skārienjutīgs ekrāns </span>;>Memory card slot: Atbalsta atmiņas kartes Micro SD līdz 64GB (iespējams lokālais ieraksts) </span>;>Selected features: Iebūvēts Wi-Fi modulis, RJ-45 ligzda, RS-485 ligzda, Strāvas izeja : 12 V DC / 200 mA, Iespēja automātiski uzņemt un saglabāt fotogrāfijas, ja nav atbildes uz zvanu pogu, Saderīgs ar videokamerām IP </span>;>Alarm signal inputs: 6 </span>;>Alarm outputs: 1 </span>;>Source of energy supply: PoE (802.3af), 12V DC </span>;
<table>
VIDEO INTERCOM:
| Compatibility: |
DAHUA |
Sensors: |
1.3 Mpx CMOS |
| Angle of visibility: |
70 ° |
Built-in proximity reader : |
 |
| LED illuminator: |
|
IR emitter: |
 |
| RS-485: |
|
Selected characteristics: |
Durvju zvana taustiņš, Iespēja pieslēgt izejas pogu un herkonu, lai kontrolētu durvju statusu, D-WDR – Wide Dynamic Range, Day/night mode – ICR automatic filter, Volume control, Two-way communication, Built-in microphone, Built-in speaker, Selecting a ringtone, LED indicator signals operating mode |
| Source of energy supply: |
From the inner panel |
Power consumed: |
≤ 3 W (režīms) ≤ 1 W (standby) |
| Hull: |
Plastic (PC + ABS) |
Colour: |
Silver + Black |
| Class of protection: |
IP66 – after additional sealing of the junction between the housing and the mounting surface, for example with silicone |
Mechanical resistance class: |
|
| Operating temperature: |
-30°C … 60°C |
Weight: |
0.13 kg (bez pārsega) 0.18 kg (ar pārsegu) |
| Size: |
131 x 46 x 34 mm (bez pārsega) 139 x 52 x 39 mm (ar pārsegu) |
INTERNAL PANEL:
| Compatibility: |
DAHUA |
Screen: |
7 " ietilpīgs skārienjutīgs ekrāns |
| Resolution: |
1024x600 |
Iekšējā atmiņa: |
|
| Memory card slot: |
Atbalsta atmiņas kartes Micro SD līdz 64GB (iespējams lokālais ieraksts) |
Selected functions: |
Interfeiss 4-Wire, Iebūvēts Wi-Fi modulis 2.4 GHz IEEE 802.11 b/g/n, RJ-45 ligzda 10/100 Mbps, RS-485 ligzda, Durvju zvana taustiņš – avārijsignalizācijas ieeja, Power output: 12 V DC / 200 mA, Built-in microphone, Built-in speaker, Two-way communication, Convenient adjustment of monitor parameters: image contrast, ringtone volume and call volume, Iespēja automātiski uzņemt un saglabāt fotogrāfijas, ja nav atbildes uz zvanu pogu, Iespēja ierakstīt īsu videoziņojumu gadījumā, ja nav atbildes uz zvana pogu, Saderīgs ar videokamerām IP, Kontroles centra publicētās informācijas saņemšana un skatīšana, Remote door opening |
| Vadāmība: |
capacitive touchscreen |
Alarm inputs: |
6 |
| Alarm outputs: |
1 |
Source of energy supply: |
PoE (802.3af), 12 V DC / 1 A (power adapter included) |
| Power consumed: |
≤ 8.9 W (režīms) ≤ 3.8 W (standby) |
Operating temperature: |
-10°C … 55°C |
| Colour: |
White |
Weight: |
0.35 kg |
| Size: |
190 x 135 x 26 mm |
VIRSAPMETUMA KORPUSS:
| Material of manufacture: |
Plastics |
Colour: |
Black |
| Weight: |
0.05 kg |
External dimensions: |
139 x 52 x 39 mm |
General information:
Language selection: |
English |
| Manufacturer / Brand: |
DAHUA |
WARRANTY: |
3 years |
