| Standard: |
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP |
| Video inputs: |
32 gab. BNC |
| Video outputs: |
1 piece HDMI 4K 1 pc. HDMI 1 pc. VGA 1 pc. Composite Video (CVBS) – Jack BNC |
| Audio input: |
4 gab. BNC , 1 gab. BNC – Mikrofons 32 Kanāli – Audio atskaņošana, izmantojot koaksiālo kabeli, tikai HD-CVI |
| Audio output: |
1 piece BNC 1 pc. BNC – Microphone |
| Image compression method: |
AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Recorded image resolution: |
AHD / HD-CVI / HD-TVI : 5M-N – 1296 x 1944 , 4M-N – 1280 x 1440 , 1080p – 1920 x 1080 , 1080N – 960 x 1080 , 720p – 1280 x 720 CVBS : 960H – 960 x 576 , IP : max. 8.3 Mpx – 3840 x 2160 |
| Recording speed adjustment: |
8.3 Mpx IP @ 1 … 25 kadru nomaiņas ātrums 5M-N @ 1 … 10 kadru nomaiņas ātrums 4M-N @ 1 … 15 kadru nomaiņas ātrums 1080p @ 1 … 15 kadru nomaiņas ātrums 1080N @ 1 … 25 kadru nomaiņas ātrums 720p @ 1 … 25 kadru nomaiņas ātrums 960H @ 1 … 25 kadru nomaiņas ātrums katram no kanāliem |
| Working mode: |
32 x AHD / HD-CVI / HD-TVI / CVBS / IP |
| Recording modes: |
Manual, sensor, motion detection, schedule |
| Supported hard drives: |
4 x 16TB SATA + 1 x eSATA |
| Backups on external media: |
Converting an image or recording frame from an archive to a USB drive |
| Searching and playing recordings: |
Recording search: by time + timeline with recording type. Playback: forward, fast, slow, step by step Advanced search (up to a second) Synchronous playback of all channels, Smart Search function 1/4/9/16 channel synchronous playback |
| Network functions: |
Full network support, Remote control of recording copying, Built-in web server max. 128 on-line users |
| USB: |
1 x USB 2.0 2 x USB 3.0 |
| Mobile phone access: |
Port: 37777 or cloud access Android: Free BCS Manager app iOS (iPhone): Free BCS Manager app |
| Alarm inputs/outputs: |
16 / 6 |
| PTZ head rotation control: |
IP Speed Dome Camera Control compatible with coax PTZ HD-CVI RS-485 – PELCO-D/P |
| Motion detection: |
Screen division: 22 x 18 motion zones |
| Selected features: |
Interfeiss RS-232 (RJ-45) Privātuma zonas – maks. 4 SMD PLUS – objekta meklēšana, kas tiek klasificēts kā: cilvēks, mehāniskais transportlīdzeklis, POS – saderīgs ar tirdzniecības vietās instalētām ierīcēm un datu attēlošanu pārklāta teksta veidā noteiktā kanāla, Inteliģenta attēla analīze : līnijas šķēršošana , ielaušanās – personu un transportlīdzekļu klasifikācija, veido detekcija |
| Mouse crew: |
– |
| IR remote control included: |
– |
| Source of energy supply: |
100V … 240V AC |
| Power consumption: |
max. 22 W (bez HDD) |
| Colour: |
Black |
| Weight: |
4.94 kg |
| Size: |
440 x 421 x 76 mm, RACK 19″, 1.5U |
| Language selection: |
Polish, English |
| Manufacturer / Brand: |
BCS Line |
| Warranty: |
3 years |
