Technical Specification:
| Standard: | CVBS – PAL / NTSC |
| Number of video outputs: | 8 pcs. BNC socket |
| Number of video inputs: | 8 pcs. screw plate |
| Number of power supply outputs: | 8 pcs cable clamps |
| Number of power supply inputs: | 3 pcs. 2.1/5.5mm jack / cable terminals |
| Maximum power supply capacity: | 10 A |
| Maximum current of one output: | 1 A |
| Fuse insert type: | 1A/250V, 5/20mm, delayed |
| Source of energy supply: | 8 … 30 V DC (typical 12V) |
| Device power consumption (for different A): | 12V = 150mA / 30V = 250mA |
| Application of LED diodes: | red “POWER” – informs about the power voltage (DC IN) green “PWR LED” – informs about the fuse being blown (lack of light means the fuse is blown) yellow “VIDEO LED” – informs about the presence of a video signal |
| Max. current: | 150mA camera – 98 meters (R=3.4Ohm/100m) 150mA camera – 60 meters (R=5.5Ohm/100m) 650mA camera + thermostat – 22 meters (R=3.4Ohm/100m) 650mA camera + thermostat – 14 meters (R=5.5Ohm/100m) |
| Assembly: | Rack 19″ |
| Housing: | Metal |
| Colour: | Black |
| Operating temperature/relative humidity: | -50 °C … 55 °C / < 95 % |
| Weight: | 0.400 kg |
| Size: | 483 x 64 x 44 mm |
| Manufacturer / Brand: | DELTA |
| Warranty: | 3 years |
