Technical Specification:
| Compatible with cards: | MIFARE 13.56 MHz |
| Card reading range: | max. 8 cm |
| Autonomous work: | – |
| Built-in keyboard: | – |
| Doorbell button: | – |
| Communication: | RS-485 |
| Sabotage output: | – |
| Source of energy supply: | 12V DC ±10% |
| Maximum power consumption: | 150mA |
| Operating temperature: | -30°C … 60°C |
| Allowable relative humidity: | 10 … 90 % (non-condensing) |
| Protection class: | IP67 |
| Housing: | Plastics |
| Colour: | Black |
| Weight: | 0.098 kg |
| Size: | 72 x 102 x 17 mm |
| Manufacturer / Brand: | DAHUA |
| Warranty: | 3 years |
