AHD, HD-CVI, HD-TVI, CVBS, TCP/IP Tīkla Video Ierakstītājs Videoreģistrators APTI-XB1612-I4 16 KANĀLI

Audio input: 6 gab. CINCH, 16 gab. Coaxial audio – Audio atskaņošana, izmantojot koaksiālo kabeli </span>; Image compression method: H.265+ </span>; Recorded image resolution: AHD / HD-TVI : 5 Mpx, 5M-N, AHD / HD-CVI / HD-TVI : 8M-N, 4 Mpx, 4M-N, 1080p, 720p, IP : max. 8.3 Mpx 4K UHD </span>; Supported hard drives: 2 x 16 TB SATA </span>;

Standard:	AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
Video inputs:	16 pcs. BNC
Video outputs:	1 pc HDMI 4K 1 piece VGA 1 piece CVBS output – BNC socket
Audio input:	6 gab. CINCH, 16 gab. Coaxial audio – Audio atskaņošana, izmantojot koaksiālo kabeli
Audio output:	1 piece CINCH
Image compression method:	H.265+ / H.265 / H.264+ / H.264
Recorded image resolution:	AHD / HD-TVI : 5 Mpx – 2560 x 1952  , 5M-N – 1280 x 1952  , AHD / HD-CVI / HD-TVI : 8M-N – 1920 x 2160  , 4 Mpx – 2560 x 1440  , 4M-N – 1280 x 1440  , 1080p – 1920 x 1080  , 720p – 1280x720, , CVBS / PAL : 960H – 960x480 IP: max. 8.3 Mpx – 3840x2160  4K UHD
Recording speed adjustment:	8.3 Mpx IP @ 1 … 25 frame rate 8M-N @ 1 … 8 5 Mpx @ 1 … 6 5M-N @ 1 … 10 frame rate 4 Mpx @ 1 … 8 4M-N @ 1 … 15 frame rate 1080p @ 1 … 15 frame rate 720p @ 1 … 25 frame rate 960H @ 1 … 25 frame rate for each of the channels
Working mode:	16x  AHD / HD-CVI / HD-TVI + 8 x IP 32 x IP All modes allow any combination of AHD, HD-CVI, HD-TVI, CVBS cameras
Recording modes:	Manual, sensor, motion detection, schedule
Supported hard drives:	2  x 16 TB SATA
Backups on external media:	Copy of the recording (.avi) in USB (pendrive) format
Searching and playing recordings:	Search for a recording in the timeline or file list. Playback: forward, backward, fast, slow. Plays recordings from up to 4 cameras simultaneously
Network interface:	1 x RJ-45 – 10/100 Base-TX
Network features:	Client program (iVMS320): live broadcast, playback and archiving of recordings IE browser: live broadcast, playback and archiving of recordings, and configuration of recorder parameters
Network protocols:	TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTP, RTSP, RTCP
ONVIF:
Default IP address:	192.168.1.88
Default username/admin password:	admin / 12345
Mobile phone access:	Port: 6000 or access via cloud Android: Free application BitVision, Android: Free application iVMS320 iOS (iPhone): Free app BitVision, iOS: Free app iVMS320
Browser access ports:	80, 5000, 554
Access ports using PC application:	80, 5000, 554
Access ports using the mobile application:	80, 5000, 6000
USB:	2 pcs. USB 2.0
Alarm inputs/outputs:	4 / 1
PTZ head rotation control:	RS-485 - PELCO-D/P
Motion detection:
Intelligent image analysis:
Selected functions:	Intelligent image analysis: Person detection Video PUSH, e-mail message Privacy zone
Mouse crew:
IR remote control included:
Source of energy supply:	12V DC / 4 A (komplektā strāvas adapteris)
Power consumed:	≤ 15 W (bez HDD)
Colour:	Black
Weight:	1.45 kg
Size:	310  x 305  x 46 mm
Language selection:	Polish, English, Bulgarian, Czech, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Turkish, Hungarian, Italian
Manufacturer / Brand:	APTI
WARRANTY:	2 years
