Resolution: 3840 x 2160, 3072 x 2048, 3072 x 1728, 2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080 Sensors: 1/2.7 " Viewing angle: 114°…32° Infrared illumination detection area: 60 m LED white light range: 60 m Memory card slot: Micro SD card support up to 512GB Image compression method: H.265+ Audio: Iebūvēts mikrofons, Audio izeja, Divvirzienu audio straumēšanas atbalsts Source of energy supply: PoE (802.3af), 12V DC
Standard: |
IP |
| Resolution: |
3840x2160 – 8 Mpx 4K UHD , 3072x2048 – 6 Mpx , 3072x1728 – 5 Mpx , 2688x1520 – 4 Mpx , 2560x1440 – 4 Mpx , 2304x1296 – 3 Mpx , 1920 x 1080 - 1080p , 1280x720 – 720p |
Sensors: |
1/2.7" Progressive Scan CMOS |
| Lens: |
2.7 … 13.5 mm – Motozoom |
Angle of visibility: |
114°…32° |
| Infrared illumination reception area: |
60 m |
LED white light range: |
60 m |
| Signal-to-sound ratio (S/N): |
> 56 dB |
Memory card slot: |
Micro SD card support up to 512GB |
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
Alarm inputs/outputs: |
1 / 1 |
| Audio: |
Built-in microphone, External microphone input, Audio output, Sound detection, Two-way audio streaming support |
Mainstream transmission speed: |
25 frame rate @ 8 Mpx |
| Network interface: |
10/100 Base-T (RJ-45) |
WEB Server: |
Built-in |
| Maximum number of online users: |
6 |
ONVIF: |
 |
| Mobile phone access: |
Port: 37777 or access via cloud Android: Free application DMSS iOS (iPhone): Free app DMSS |
Default IP address: |
192.168.1.108 |
| Default username/admin password: |
admin / – Administrator password must be set during first launch |
Browser access ports: |
80, 37777 |
| Access ports using PC application: |
37777 |
Access ports using the mobile application: |
37777 |
| ONVIF socket: |
80 |
RTSP URL: |
rtsp://admin:password@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 – Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 – Sidestream |
| Intelligent image analysis: |
burglary – classification of persons and vehicles crossing the line – classification of persons and vehicles SMD 4.0 – objekta meklēšana, kas klasificēts kā: cilvēks, mehānisks transportlīdzeklis |
Selected functions: |
When Smart Dual Light is active, the white light automatically turns on when an object is detected in the monitoring field, significantly improving image quality AcuPick support – technology that uses artificial intelligence both front-end and back-end to search through huge amounts of video data and quickly locate targets with high accuracy AI SSA – AI Smart Scene Adaptive – automatic scene adjustment using deep learning algorithms to detect environmental conditions such as rain, fog, backlight, low light and flicker to set optimal image parameters Compatible with NAS – Network Attached Storage Motozoom lens WDR – 120 dB – Wide dynamic range of lighting 3D-DNR - Digital Noise Reduction ROI – improving the quality of selected image fragments BLC/HLC – Backlight/High Light Compensation F-DNR (Defog) – Precipitation Noise Reduction EIS – Electronic Image Stabilizer Ability to change resolution, quality and bitrate Image rotation and mirroring Motion detection – max. 4 configurable zones Privacy zones – max. 4 |
| Source of energy supply: |
PoE (802.3af), 12 V DC / 850 mA (max) |
Power consumed: |
≤ 9.9 W @ 12 V DC ≤ 12.5 W @ PoE |
| Hull: |
Compact – Metal |
Colour: |
Black |
| Class of protection: |
IP67 |
Mechanical protection class: |
 |
| Operating temperature: |
-30°C … 60°C |
Weight: |
0.84 kg |
| Size: |
238 x 91 x 91 mm |
Language selection: |
poļu, angļu, čehu, franču, spāņu, Holandiešu, vācu, krievu, portugāļu, rumāņu, turku, ukraiņu, ungāru, itāļu |
| Manufacturer / Brand: |
DAHUA |
WARRANTY: |
3 years |
