Name: DAHUA IP Tīkla Video Ierakstītājs Videoreģistrators NVR616RH-32-XI 32 KANĀLI WizMind
SKU: NVR616RH-32-XI
Availability: OutOfStock

DAHUA IP Tīkla Video Ierakstītājs Videoreģistrators NVR616RH-32-XI 32 KANĀLI WizMind

Preces kods: NVR616RH-32-XI

Piegādes laiks: 27-30 Aprīlī

Estimated Delivery Dates

6734,44 €

Availability: 0

The network video recorder is equipped with an advanced image analysis function; Supported resolution: max. 32 Mpx ;>Audio support: 32 Channels – Audio from cameras, Sound detection ;>Audio input: 1 pc. CINCH ;>Audio output: 2 pcs CINCH ;>Image compression method: Smart H.265+ ;>Supported hard drives: 16 x 20 TB SATA + 1 x eSATA, Raid 0/1/5/6/10 ;>Alarm inputs/outputs: 32 / 16 ;>Selected features: Intelligent image analysis, face detection, Face recognition ;>Source of energy supply: Backup power supply ; <table>

Standard:
IP
Supported resolution:
max. 32 Mpx

Video outputs:

2 gab. HDMI 4K

1 gab. HDMI 8K

1 piece HDMI

2 pcs. VGA
Audio support:

32 Channels – Audio from cameras,

Two-way audio streaming support

Sound detection

Audio input:
1 piece CINCH
Audio output:
2 pcs. CINCH

Image compression method:
Smart H.265+ / H.265 / Smart H.264+ / H.264
Bit transmission:
max. 1280 Mbps

Supported hard drives:
16 x 20 TB SATA + 1 x eSATA ,
Raid 0/1/5/6/10
Recording modes:
Manual, sensor, motion detection, schedule

Backups on external media:
Backup to USB (pendrive, external drive)
Searching and playing recordings:

Search for recordings by time and event type. Playback: forward, backward, speed up, slow down

Advanced search (up to a second)

Smart Playback function

Plays recordings from up to 16 cameras simultaneously

Network interface:
4 times RJ-45 10/100/1000/2500 Base-TX
Network features:
Full network support, Remote recording copy, Built-in web server

ONVIF:
22.06
Default IP address:
192.168.1.108

Default username/admin password:
admin / –
Administrator password must be set during first launch
Mobile phone access:
Port: 37777 or access via cloud

Android: Free application DMSS

iOS (iPhone): Free app DMSS

Watch the video on how to perform P2P configurations on Dahua recorders and how to enable the mobile app

Browser access ports:
80, 37777
Access ports using PC application:
37777

Access ports using the mobile application:
37777
RTSP URL:

rtsp://admin:password@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 – Main stream

rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 – Sidestream

USB:

2 pcs. USB 2.0

2 pcs. USB 3.0
Regular ports:

2 pcs. RS-485

1 gab. RS-232

Alarm inputs/outputs:
32 / 16
PTZ head rotation control:

IP Speed Dome cameras

RS-485 - PELCO-D/P and others

Intelligent image analysis:

Motion detection:

Selected functions:

Intelligent image analysis: IVS analysis – 10 rules, change of scene, detection,

SMD PLUS – search for an object classified as: person, motor vehicle, non-motorized vehicle

False alarm filtering based on person and vehicle recognition

Facial recognition – compatible with 6 facial attribute extraction types

Real-time facial recognition and analysis (max. 16 images per second)

Izmanto līdz 40 sejas datu bāzēm, ieskaitot 300 000 sejas attēlus

metadata processing – automatic photo capture and information collection that further helps identify persons and vehicles that triggered the alarm (clothing, silhouette, face, characteristics of motorized and non-motorized vehicles)

AcuPick support – technology that uses artificial intelligence both front-end and back-end to search through huge amounts of video data and quickly locate targets with high accuracy

EPTZ – advanced target detection and tracking algorithms that trigger alarms, can zoom in and track multiple people and/or vehicles simultaneously

The functions are implemented by the video recorder in cooperation with cameras that support these functions:

ANPR

Lists of authorized and unauthorized license plates: up to 20,000 entries

person/vehicle registration

estimate of the size of the audience gathered

temperature map
Mouse crew:

IR remote control included:

Switch PoE:

Source of energy supply:

100 … 240 V AC @ 50 ± 2 Hz

Backup power supply
Power consumed:
max. 25 W (bez HDD)

Operating temperature:
-10°C … 55°C
Weight:
13.03 kg

Size:
485 x 529 x 133 mm
Language selection:
Polish, English

Manufacturer / Brand:
DAHUA
WARRANTY:
3 years

Additional information

Svars	15,4200 kg
Dimensions	634 × 709 × 429 cm

DAHUA IP Tīkla Video Ierakstītājs Videoreģistrators NVR616RH-32-XI 32 KANĀLI WizMind
