| Standard: |
TCP/IP |
| Supported resolution: |
max. 8 Mpx - 3840 x 2160 px, 4K UHD |
| Video outputs: |
1 pc. HDMI 4K 1 pc. VGA It is possible to configure the SPOT function on one of the outputs |
| Audio support: |
32 Channels – Audio from cameras |
| Audio input: |
1 pc. CINCH |
| Audio output: |
1 pc. CINCH |
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 / MPEG-4 |
| Supported hard drives: |
2 x 6TB SATA |
| Recording modes: |
Manual, motion detection, schedule |
| Network protocols: |
TCP/IP, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS, P2P, ONVIF |
| Backups on external media: |
Backup to USB (pendrive, external drive) |
| Default username/admin password: |
admin / – Administrator password must be set during first launch |
| Default IP address: |
DHCP or 192.168.1.64 |
| Browser access ports: |
80 |
| Access ports using PC application: |
Port: 8000 or access via cloud |
| Access ports using the mobile application: |
8000 |
| RTSP URL: |
rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no01/ – Main stream rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no02/ – Side stream |
| Searching and playing recordings: |
Search for recordings by time and event type. Playback: forward, backward, speed up, slow down |
| Bit transmission: |
max. 256 Mbps |
| Network functions: |
Viewing images, Playing recordings, Backing up recordings |
| ONVIF: |
– |
| Intelligent image analysis: |
crossing the line, trespassing |
| Mobile phone access: |
Port: 8000 or cloud access Android: Free BCS View app iOS (iPhone): Free BCS View app |
| Alarm inputs/outputs: |
4 / 1 |
| PTZ head rotation control: |
IP Speed Dome cameras |
| USB: |
1 pc USB 2.0 1 pc USB 3.0 |
| Motion detection: |
– |
| Mouse crew: |
– |
| IR remote control included: |
– |
| Operating temperature: |
-10°C … 55°C |
| Source of energy supply: |
12 V DC / 3.33 A (power adapter included) |
| Weight: |
1.77 kg |
| Size: |
385 x 315 x 52 mm |
| Language selection: |
Polish, English |
| Manufacturer / Brand: |
BCS View |
| Warranty: |
3 years |
